1 General Features Diagonal Size 3.4 inch Type a-Si TFT-LCD, LCM Pixel Format 800(RGB)*800 Configuration RGB Vertical Stripe Active Area 87.6(H)*87.6(V) mm Outline Dim. 99(H)*96.6(V) mm Bezel Area – Treatment Hard coating (7H) Luminance 350 Cd/m² (Typ.) Contrast Ratio 800:1 (Typ.) (TM) View Direction Symmetry Response Time 25 (Typ.)(Tr Td) Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Operating Mode SFT, Normally Black, Transmissive Support Color 16.7M 70% (CIE1931) Light Source WLED [2S4P] , 30K hours , W/O Driver Weight TBD Designed For Industrial Application,meter, Smart wearable , Raspbery Pi Frame Rate – Touch Panel PCAP Interface Type 39 pins MIPI (3 data lanes) , FPC Power Supply 1.8/5.0/-5.0V (Typ.)(IOVCC/VDD/-VDD) Environment Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
